Sargent

Sargent 465 Single Cylinder Deadbolt

$98.19
Usually Ships:  1-2 Business Days
  • ANSI/BHMA A156.36, Grade 2
  • Single Cylinder x Inside Turn
  • UL-cUL Fire-Rated Up to 3 Hours

Available Options:

Clear

Product Overview

Sargent 465 Single Cylinder Deadbolt, Grade-2, 2-3/4" Backset

Ideally suited for standard applications, the 460 Series is a cylindrical deadbolt that is certified to ANSI/BHMA A156.36 Grade 2 standards.

ANSI E0151 Single Cylinder Deadlock

  • Key outside operates deadbolt
  • Thumbturn inside operates deadbolt
Brand

Finishes

US26D (626) Satin Chrome, US10B (613) Oil Rubbed Bronze, US26 (625) Bright Chrome, US3 (605) Bright Brass, US4 (606) Satin Brass, BSP - Black Suede Powder Coat, US10BE (613e) Dark Oxidized Satin Bronze, Equivalent

ANSI/BHMA Standard

ANSI/BHMA A156.36, Grade 2

Usage

Medium Duty

ANSI Function

E0151

Deadbolt Type

Single Cylinder

Cylinder & Keys

6-pin conventional, keyed different, with 2 keys

Keyway

Sargent LA Keyway

Bolt

1" throw bolt, 1-1/8" x 2-1/4" square corner face plate

Backset

2-3/4"

Strike

1-1/8” x 2-3/4“ square corner

Fire-Rating

Fire Rated - UL10C - Positive Pressure
