Pemko

Pemko 357 Overlapping Astragal

$59.78
Usually Ships:  1-2 Business Days
  • Used to seal gap between pair of doors
  • Surface mounts to one door (overlaps the other)
  • Includes pre-drilled holes and screws

Available Options:

Clear

Product Overview

Pemko 357 11 Gauge Overlapping Astragal

The 357 Overlapping Meeting Stile System is a high-quality solution for double-door entryways. This system boasts versatile models, such as the ND option requiring no drilling, or the inclusion of the S88 adhesive gasketing. It prevents drafts, light, smoke, and moisture from infiltrating while providing a seamless seal between the doors. It can be cut to size and can be used with optional Silicone Teardrop Weatherstrip for better sealing properties. This system is compliant with smoke, fire, and air infiltration standards.

  • PROFILE WIDTH: 2” (50.8 mm)
  • HEIGHT: 1/8” (3.2 mm)
  • LENGTHS: 84" or *96"

*excessive length shipping fee applies

  • 357C: C - Clear Anodized Aluminum
  • 357BSP: BSP - Black Suede Powder Coat
  • 357D: D - Dark Bronze Anodized Aluminum
  • 357SP: Steel, Galvannealed (Primed Gray)
  • 357SS: SS - Stainless Steel
  • 357WSP: WSP - White Suede Powder Coat

Ratings

  • Air Infiltration Tested
  • Fire Rated - UL10C - Positive Pressure
  • Underwriters Laboratory 4L10

Smoke ratings apply to SP and SS finishes when used in conjunction with S88 Smoke Seal

Brand

Finishes

BSP - Black Suede Powder Coat, WSP - White Suede Powder Coat, C – Clear Anodized Aluminum, D – Dark Bronze Anodized Aluminum, SS – Satin Stainless Steel, SP - Steel, Galvannealed (Primed Gray)

Length

84", 96"

Fire-Rating

Fire Rated - UL10C - Positive Pressure
